6SR

Applications

For water supply from wells or reservoirs

For domestic use,for civil and industrial applications

For garden use and irrigation

Operateing conditions

Maximum fluid temperature up to +35℃

Maximum sand content:0.25%

Maximum well diameter:3"

Motor and Pump

Rewindable motor

Single-phase:220-240V/50Hz

Three-phase:380-415V/50Hz

Equip with start control box or digital auto-control box

Pumps are designed by casing stressed

Curve tolerance according to ISO9906

Options on request

Special mechanical seal

Other voltages or frequency 60Hz

Single phase motor with built-in capacitor

Warranty: 12 months

(according to our general sales conditions )
