Deep well all stainless steel pump 6SP
6SP series is all stainless steel pump，with edible oil filled motor, stable,it is suitable for house and clean water use, reliable running with pressure regulating membrane;Single phase motor equipped with start box which built in capacitor ¤t mode thermal protector, convenient for replacement;Pump sleeve with screw thread, single stage floating impellers;
- Model Number：6SP
- ：0086-18806865216
Applications
◎For water supply from wells or reservoirs
◎For domestic use,for civil and industrial applications
◎For garden use and irrigation
Operateing conditions
◎Maximum fluid temperature up to +35℃
◎Maximum sand content:0.25%
◎Maximum well diameter:6"
Motor and Pump
◎Rewindable motor
◎Single-phase：220-240V/50Hz
◎Three-phase：380-415V/50Hz
◎①Direct start（1 cable）
◎②Start-delta start（2 cables）
◎Equip with start control box or digital auto-control box
◎NEMA dimensions standards
◎Curve tolerance according to ISO 9906
Warranty: 12 months
(according to our general sales conditions )
| Components | Material | ||||
| Delivery casing | AISI 304 SS | ||||
| Suction lantern | AISI 304 SS | ||||
| Diffuser | AISI 304 SS | ||||
| Impeller | AISI 304 SS | ||||
| Shaft | AISI 304 SS | ||||
| Shaft coupling | AISI 304 SS | ||||
| Wear ring | Rubber | ||||
| Motor external casing | AISI 304 SS | ||||
| Top chock | Cast-iron ASTM NO.30 | ||||
| Bottom support | Cast-iron ASTM NO.30 | ||||
| Seal | NBR Graphite-SIC/TC | ||||
| Shaft | AISI 304 SS-ASTM 5140 | ||||
